Elma Cyclomotion - Watch Winding Machine

The Elma Cyclomotion is a professional machine for the winding of automatic watches and is the perfect modern evolution of the proven Cyclomat. Used for the servicing and maintance of automatic watches this watch winder can be configured individually and for the respective requirements so the watch can simulate any possible wrist position. Different rotation variants guarantee optimum winding according to the respective requirements of the mechanical watch movements. In addition large and heavy mechanical watches can also be wound easily by the powerful yet very quiet motor. As a result, the Cyclomotion is optimally designed for service workshops, watchmakers and watch manufactures.

Features include: Powerful, quiet motor with integrated slip clutch and holding torque (in standby mode), Adjustable speed: 1 rpm or 4 rpm for continuous tests and fast winding of the watches, Adjustable rotation directions: clockwise, anti-clockwise and clockwise / anticlockwise by rotation direction change, Individually selectable retaining bracket combination enables simultaneous winding on one or both sides of watch movements to be wound, (Lockable protection cover provides additional protection against dust and mechanical influence - Optional, protective cover sold separately).

Elma Cyclomotion Specifications:

• Dimensions – 465mm x 325mm x 520mm (LxWxH)
• Weight – 11.0 kg
• Mains Frequency – 50/60 Hz
• Rotation - Radial (RPM) - 1 or 4
• Rotation - Axial (RPM) - 4.5 or 18
• Rotation Direction - Left/Right
• Power Consumption – 24 Watt
• Voltage – 100-240 Volt
• Made in Germany
