Ultrasonics, Baskets, Dryers & Steam Cleaners

Basket for Elma Ultrasonic Machines

Stock # Item Price Order QTY
EL-1004170 Stainless Steel Holder Basket Type S 10 (H): 19x8.5cm for Elmasonic Type 1001214
EL-1004176 S/S Basket for Elmasonic S 30 H - 198x106mm
EL-1004243 S/S Basket for Elmasonic S 60 H - 255x115mm
EL-1004275 Stainless Steel Holder Basket Type 180: 280x250mm for Elmasonic Type 180
EL-1004277 S/S Basket for Elmasonic S 120 H - 250x190mm
LR-11086 Basket for Quantrex 90H
LR-11088 Basket for Quantrex 140H

10.8 L Ultrasonic with Heater Analog and Digital(s)

2 Different Operating systems are available.

  • Model T-JP-040 is Analog
  • T-JP-040s is Digital.

Specification:
Ultrasonic frequency : 40,000 Hz
The tank material :  stainless steel SUS30
Shell material : SUS201
Timer: 1~30 min adjustable
Heater: Normal ~80℃ adjustable
Power : AC 100 ~ 120 V, 60 Hz/AC 200 ~ 240 V, 50 Hz
Ultrasonic power : 240W, 4 transducers
Heating power : 200 W
Tank size  : 300 x 240 x 150MM(L x W x H)
Unit  size : 380 x 290 x 280MM(L x W x H)
Packing size : 435 x 360 x 350MM (L x W x H)
Net weight: 7.3 kg

Stock # Item Price Order QTY
Popular
 T-JP-040 10.8 L Analogue Ultrasonic with Heater
Popular
 T-JP-040S 10.8 L Ultrasonic with Heater (Digital)

6.5L Ultrasonic with Heater

Ultrasonic Frequency 40,000 Hz Material Stainless Steel SUS30
Tank Capacity 6.5 L
Timer 1-30minutes,  Digital  timer
Power Supply AC 100 ~ 120V, 50 / 60Hz AC 220 ~ 240V, 50 / 60 Hz
Ultrasonic Power 180W
Heating Power 150 W, D
Digital Heating Unit  Size 325 x 180 x 280 mm  ( L x W x H )
Tank Size 300 x 150 x 150 mm  ( L x W x H )
Package Size 430 x 280 x 380 mm  ( L x W x H ) N.W. 6.0 kg G.W. 6.7 kg

Stock # Item Size Price Order QTY
Popular
 T-JP-031S 6.5L Ultrasonic with Heater 6.5 ltr

Elmasonic S 10 H

The new Elmasonic S units are State-of-the art microprocessor controlled ultrasonic cleaners which feature sweep technology for an optimised sound field distribution in the cleaning liquid by frequency modulation, controlled by a high-performance 37 kHz sandwich transducer systems.

Features include: Cavitation-resistant stainless steel cleaning tank, User-friendly and clear operating panel with LED-display for ultrasonic and heating function, Turning knob for setting continued and short-period operation from 1 to 30 min, Temperature-controlled ultrasonic operation (applies only for units with heating), Degas function for the efficient degassing of the cleaning liquid and for laboratory purposes, Auto degas function for automatic degassing cycles, i.e. with fresh cleaning liquids, Dry-run protected heating (applies only for units with heating).

Elmasonic S10H Specifications:

  • Tank Volume Max - 0.8 Litre
  • Unit Outer Dimensions - 206mm x 116mm x 178mm (LxWxH)
  • Tank Internal Dimensions - 190mm x 85mm x 60mm (LxWxH)
  • Basket Internal Dimensions - 177mm x 73mm x 30mm (LxWxH)
  • Weight - 2.0 kg
  • Operating Frequency - 37 kHz
  • Ultrasonic Peak Performance Max - 240 Watt
  • Heating Power - 60 Watt
  • Power Consumption - 90 Watt
  • Voltage - 220-240 Volt
  • Timer Function
  • Sweep Function
  • Degas Function
  • Cover Included
  • Made in Germany
Stock # Item Price Order QTY
Premium (Professional)
 EL-1001214 Elmasonic S 10 (H)
Premium (Professional)
 EL-1003278 Plastic Cover for Elmasonic Type 10

Elmasonic S 15 H

The new Elmasonic S units are State-of-the art microprocessor controlled ultrasonic cleaners which feature sweep technology for an optimised sound field distribution in the cleaning liquid by frequency modulation, controlled by a high-performance 37 kHz sandwich transducer systems.

Features include: Cavitation-resistant stainless steel cleaning tank, User-friendly and clear operating panel with LED-display for ultrasonic and heating function, Turning knob for setting continued and short-period operation from 1 to 30 min, Temperature-controlled ultrasonic operation (applies only for units with heating), Degas function for the efficient degassing of the cleaning liquid and for laboratory purposes, Auto degas function for automatic degassing cycles, i.e. with fresh cleaning liquids, Dry-run protected heating (applies only for units with heating).

Elmasonic S15H Specifications:

  • Tank Volume Max - 1.75 Litre
  • Unit Outer Dimensions - 175mm x 180mm x 212mm (LxWxH)
  • Tank Internal Dimensions - 151mm x 137mm x 100mm (LxWxD)
  • Basket Internal Dimensions - 112mm x 103mm x 50mm (LxWxH)
  • Weight - 2.1 kg
  • Operating Frequency - 37 kHz
  • Ultrasonic Peak Performance Max - 280 Watt
  • Heating Power - 60 Watt
  • Power Consumption - 95 Watt
  • Voltage - 220-240 Volt
  • Timer Function
  • Sweep Function
  • Degas Function
  • Made in Germany
Stock # Item Price Order QTY
Premium (Professional)
 EL-1002060 Elmasonic S 15 (H)
Premium (Professional)
 EL-1003280 Plastic Cover for Elmasonic Type 15

Elmasonic S 30 H

The new Elmasonic S units are State-of-the art microprocessor controlled ultrasonic cleaners which feature sweep technology for an optimised sound field distribution in the cleaning liquid by frequency modulation, controlled by a high-performance 37 kHz sandwich transducer systems.

Features include: Cavitation-resistant stainless steel cleaning tank, User-friendly and clear operating panel with LED-display for ultrasonic and heating function, Turning knob for setting continued and short-period operation from 1 to 30 min, Temperature-controlled ultrasonic operation (applies only for units with heating), Degas function for the efficient degassing of the cleaning liquid and for laboratory purposes, Auto degas function for automatic degassing cycles, i.e. with fresh cleaning liquids, Dry-run protected heating (applies only for units with heating).

Elmasonic S30H Specifications:

  • Tank Volume Max - 2.75 Litre
  • Unit Outer Dimensions - 300mm x 179mm x 214mm (LxWxH)
  • Tank Internal Dimensions - 240mm x 137mm x 100mm (LxWxD)
  • Basket Internal Dimensions - 198mm x 106mm x 50mm (LxWxH)
  • Weight - 3.3 kg
  • Operating Frequency - 37 kHz
  • Ultrasonic Peak Performance Max - 320 Watt
  • Heating Power - 200 Watt
  • Power Consumption - 280 Watt
  • Voltage - 220-240 Volt
  • Timer Function
  • Sweep Function
  • Degas Function
  • Tank Drain
  • Made in Germany
Stock # Item Price Order QTY
Premium (Professional)
 EL-1001955 Elmasonic S 30 (H)
Premium (Professional)
 EL-1003281 Plastic Cover for Elmasonic Type 30/40
Premium (Professional)
 EL-1004176 S/S Basket for Elmasonic S 30 H - 198x106mm

Elmasonic S 40 H

The new Elmasonic S units are State-of-the art microprocessor controlled ultrasonic cleaners which feature sweep technology for an optimised sound field distribution in the cleaning liquid by frequency modulation, controlled by a high-performance 37 kHz sandwich transducer systems.

Features include: Cavitation-resistant stainless steel cleaning tank, User-friendly and clear operating panel with LED-display for ultrasonic and heating function, Turning knob for setting continued and short-period operation from 1 to 30 min, Temperature-controlled ultrasonic operation (applies only for units with heating), Degas function for the efficient degassing of the cleaning liquid and for laboratory purposes, Auto degas function for automatic degassing cycles, i.e. with fresh cleaning liquids, Dry-run protected heating (applies only for units with heating).

Elmasonic S40H Specifications:

  • Tank Volume Max - 4.25 Litre
  • Unit Outer Dimensions - 300mm x 179mm x 264mm (LxWxH)
  • Tank Internal Dimensions - 240mm x 137mm x 150mm (LxWxD)
  • Basket Internal Dimensions - 190mm x 105mm x 75mm (LxWxH)
  • Weight - 4.0 kg
  • Operating Frequency - 37 kHz
  • Ultrasonic Peak Perfomance Max - 560 Watt
  • Heating Power - 200 Watt
  • Power Consumption - 340 Watt
  • Voltage - 220-240 Volt
  • Timer Function
  • Sweep Function
  • Degas Function
  • Tank Drain
  • Made in Germany
Stock # Item Price Order QTY
Premium (Professional)
 EL-1002006 Elmasonic S 40 (H)
Premium (Professional)
 EL-1003281 Plastic Cover for Elmasonic Type 30/40

Elmasonic S 60 H

The new Elmasonic S units are State-of-the art microprocessor controlled ultrasonic cleaners which feature sweep technology for an optimised sound field distribution in the cleaning liquid by frequency modulation, controlled by a high-performance 37 kHz sandwich transducer systems.

Features include: Cavitation-resistant stainless steel cleaning tank, User-friendly and clear operating panel with LED-display for ultrasonic and heating function, Turning knob for setting continued and short-period operation from 1 to 30 min, Temperature-controlled ultrasonic operation (applies only for units with heating), Degas function for the efficient degassing of the cleaning liquid and for laboratory purposes, Auto degas function for automatic degassing cycles, i.e. with fresh cleaning liquids, Dry-run protected heating (applies only for units with heating).

Elmasonic S60H Specifications:

  • Tank Volume Max - 5.75 Litre
  • Unit Outer Dimensions - 365mm x 186mm x 264mm (LxWxH)
  • Tank Internal Dimensions - 300mm x 151mm x 150mm (LxWxD)
  • Basket Internal Dimensions - 255mm x 115mm x 75mm (LxWxH)
  • Weight - 5.1 kg
  • Operating Frequency- 37 kHz
  • Ultrasonic Peak Performance Max - 600 Watt
  • Heating Power - 400 Watt
  • Power Consumption - 550 Watt
  • Voltage - 220-240 Volt
  • Timer Function
  • Sweep Function
  • Degas Function
  • Tank Drain
  • Made in Germany
Stock # Item Price Order QTY
EL-1002238 Elmasonic S 60 (H)
EL-1003282 Cover for Elmasonic S 60 H
EL-1004243 S/S Basket for Elmasonic S 60 H - 255x115mm

Elmasonic Easy 20 H

The new Elmasonic EASY ultrasonic range by Elma is designed and manufactured in Germany to meet the highest engineering standards. This range was created to handle any cleaning task quickly and efficiently whilst being as simple and user-friendly to operate. As with the Elmasonic S range these units are also a microprocessor-controlled ultrasonic with sweep technology offering a state-of-the-art solution.

Features include: Efficient 37 kHz ultrasonic high-performance transducers, Cleaning tank made of cavitation-resistant stainless steel, User-friendly and clearly arranged operating panel; sealed against liquid intrusion to protect the electronics, LED display for ultrasonic function, Rotary switch for easy preselection of the cleaning time, Continuous operating or short-term operation between 1 and 30 minutes, Permanent sweep function for optimized sound field distribution through frequency modulation, Dry-run protected heating, Temperature selectable by rotary switch; from 30°C to 80°C in increments of 5°C, LED display for heating operation, Detachable power cord with IEC plug, Selectable temperature threshold with alarm, Automatic safety shutdown after 8 hours of continuous operation, Automatic safety shutdown at a bath temperature of 90 °C & Pulse“ function.

Elmasonic Easy 20H Specifications:

  • Tank Volume Max - 1.75 Litre
  • Unit Outer Dimensions - 176mm x 176mm x 219mm (LxWxH)
  • Tank Internal Dimensions - 137mm x 123mm x 99mm (LxWxD)
  • Basket Internal Dimensions - 112mm x 103mm x 50mm (LxWxH)
  • Weight - 2.1 kg
  • Operating Frequency - 37 kHz
  • Ultrasonic Peak Performance Max - 280 Watt
  • Heating Power - 120 Watt
  • Power Consumption - 155 Watt
  • Voltage - 220-240 Volt
  • Timer Function
  • Sweep Function (Permanent)
  • Pulse Function (Optional)
  • Made in Germany
Stock # Item Price Order QTY
Premium (Professional)
 EL-1071652 Elmasonic Easy 20 H - 1.75 Litres
Premium (Professional)
 EL-1071694 Plastic Cover for Elmasonic Type 20

Elmasonic Easy 30 H



The new Elmasonic EASY ultrasonic range by Elma is designed and manufactured in Germany to meet the highest engineering standards. This range was created to handle any cleaning task quickly and efficiently whilst being as simple and user-friendly to operate. As with the Elmasonic S range these units are also a microprocessor-controlled ultrasonic with sweep technology offering a state-of-the-art solution.

Features include: Efficient 37 kHz ultrasonic high-performance transducers, Cleaning tank made of cavitation-resistant stainless steel, User-friendly and clearly arranged operating panel; sealed against liquid intrusion to protect the electronics, LED display for ultrasonic function, Rotary switch for easy preselection of the cleaning time, Continuous operating or short-term operation between 1 and 30 minutes, Permanent sweep function for optimized sound field distribution through frequency modulation, Dry-run protected heating, Temperature selectable by rotary switch; from 30°C to 80°C in increments of 5°C, LED display for heating operation, Detachable power cord with IEC plug, Selectable temperature threshold with alarm, Automatic safety shutdown after 8 hours of continuous operation, Automatic safety shutdown at a bath temperature of 90 °C & Pulse“ function.

Elmasonic Easy 30H Specifications:

  • Tank Volume Max - 2.75 Litre
  • Unit Outer Dimensions - 264mm x 176mm x 219mm (LxWxH)
  • Tank Internal Dimensions - 225mm x 124mm x 99mm (LxWxD)
  • Basket Internal Dimensions - 198mm x 106mm x 50mm (LxWxH)
  • Weight - 3.3 kg
  • Operating Frequency - 37 kHz
  • Ultrasonic Peak Performance Max - 320 Watt
  • Heating Power - 200 Watt
  • Power Consumption - 280 Watt
  • Voltage - 220-240 Volt
  • Timer Function
  • Sweep Function (Permanent)
  • Pulse Function (Optional)
  • Made in Germany
Stock # Item Price Order QTY
Premium (Professional)
 EL-1003281 Plastic Cover for Elmasonic Type 30/40
Premium (Professional)
 EL-1004176 S/S Basket for Elmasonic S 30 H - 198x106mm
Premium (Professional)
 EL-1071656 Elmasonic Easy 30 H - 2.75 Litres
