Elmasonic Easy 20 H

The new Elmasonic EASY ultrasonic range by Elma is designed and manufactured in Germany to meet the highest engineering standards. This range was created to handle any cleaning task quickly and efficiently whilst being as simple and user-friendly to operate. As with the Elmasonic S range these units are also a microprocessor-controlled ultrasonic with sweep technology offering a state-of-the-art solution.

Features include: Efficient 37 kHz ultrasonic high-performance transducers, Cleaning tank made of cavitation-resistant stainless steel, User-friendly and clearly arranged operating panel; sealed against liquid intrusion to protect the electronics, LED display for ultrasonic function, Rotary switch for easy preselection of the cleaning time, Continuous operating or short-term operation between 1 and 30 minutes, Permanent sweep function for optimized sound field distribution through frequency modulation, Dry-run protected heating, Temperature selectable by rotary switch; from 30°C to 80°C in increments of 5°C, LED display for heating operation, Detachable power cord with IEC plug, Selectable temperature threshold with alarm, Automatic safety shutdown after 8 hours of continuous operation, Automatic safety shutdown at a bath temperature of 90 °C & Pulse“ function.

Elmasonic Easy 20H Specifications:

• Tank Volume Max - 1.75 Litre
• Unit Outer Dimensions - 176mm x 176mm x 219mm (LxWxH)
• Tank Internal Dimensions - 137mm x 123mm x 99mm (LxWxD)
• Basket Internal Dimensions - 112mm x 103mm x 50mm (LxWxH)
• Weight - 2.1 kg
• Operating Frequency - 37 kHz
• Ultrasonic Peak Performance Max - 280 Watt
• Heating Power - 120 Watt
• Power Consumption - 155 Watt
• Voltage - 220-240 Volt
• Timer Function
• Sweep Function (Permanent)
• Pulse Function (Optional)
• Made in Germany
